Helicopter Loading Bag
Product Options
| Size: |
|
|
 Ruth Lee Helicopter Loading Bag Ruth Lee Helicopter Loading Bag Ruth Lee Helicopter Loading Bag |
|
This hard-wearing and high-specification bag has been designed to transport firefighting equipment via helicopter and sea-going tug directly on to the ship affected.
Helicopter Kit Bags manufactured
The base of the helicopter loading bag is constructed in two parts.
The outer base (bottom tray) is constructed with large radii corners to avoid damage to helicopter flooring.
The standard Size is 36" x 25" nominal with 8 gauge bases manufactured from Carbon Kevlar.
The bases are secured through the bottom of the bag and the webbing straps by steel bolts with Nyloc nuts.
All seams are double-stitched, and a 200mm rubbing band, manufactured from black PVC Nylon, is added to the bottom of the bag.
The exterior is manufactured from high-visibility orange Nylon with clear label pouches for easy insertion and removal of labels/instructions.
The standard size Helicopter Loading bag will hold 6/8 kit bags.
The small will hold 4-6 kit bags.
NATO Stock Number: 8465-991-561-438
SPECIAL MATERIALS:
7oz PU Nylon outer covering
10mm Plastozote Foam sandwich
4oz PU Nylon inner
PVC Nylon base
Heavy Duty Glass Fiber tray
8mm Heavy duty zip
48mm Heavy duty webbing / 26 KN *
Steel Carabiner
Dimensions, Standard
Length - 36" (915mm)
Width - 25" (635mm)
Height - 25" (635mm)
SWL - 220 lbs (100Kg)
Dimensions, Small
Length - 26" (650mm)
Width - 18" (450mm)
Height - 20" (500mm)
SWL - 132 lbs (60 kg)
|
|
Catalog PDF,37.3 MB
|
|
